Diesel Particulate Filter Silicon Carbide Ceramic Membrane
Advantages of Recrystallized Silicon Carbide DPF
Firstly,the silicon carbide diesel particulate filter(DPF) adopts a unique "chessboard" honeycomb porous structure, and through a precisely controlled alternating sealing design, SiC filter membrane forces the airflow to completely penetrate the porous ceramic wall. During this process, the particles in the flue gas collide violently with the porous structure and are efficiently intercepted, achieving a highly efficient capture effect far beyond traditional surface filtration methods, diesel particulate filter(DPF) is particularly suitable for treating ultrafine particles and high-temperature smoke.
Secondly, SiC filter membrane has excellent extreme environmental resistance, with a maximum operating temperature of 1600 ℃, and can operate stably for a long time in ultra-high temperature environments such as gas turbine exhaust, steel furnaces, and high load diesel engine emissions.
Thirdly, honeycomb silicon carbide ceramic membrane have excellent chemical stability. silicon carbide ceramic membrane maintains excellent antioxidant performance in high temperature environments.
More importantly, silicon carbide ceramic membrane has ultra long durability, matching the entire lifecycle of commercial vehicles. SiC filter membrane has high mechanical strength, strong resistance to carbon deposition and ash blockage, and does not require frequent replacement or maintenance, greatly reducing system operating costs.
Finally, SiC filter membranes have good system integration compatibility. silicon carbide ceramic membrane can be used independently as a high-performance particulate matter capture unit (DPF, diesel particulate filter), providing pollution prevention solutions for diesel vehicles, non road machinery, and fixed source control.
MAIN PARAMETER
SiC filter membrane Industry | RSiC |
SiC Content (%) | ≥99% |
Bulk Density (g/cm3) | 2.65~2.75 |
Apparent Porosity (%) | <17 |
Room temperaturestrength (MPa) | 90~100 |
Strengthat 1300℃(MPa) | 100-110 |
Elasticity modulus at 20℃ | 240 |
Thermal Conductivity At 1200℃(W/mk) | 36 |
Thermal Expansion x10-6/℃ | 4.6 |
Max Using Temperature（℃） | 1650℃ |
Hardness At 20°C (Kg/mm2) | 2000 |
Fracture Toughness At 20°(MpaxM1/2) | 2.0 |
PRODUCT DETAIL
Honeycomb structured silicon carbide ceramic is a high-performance functional ceramic with a three-dimensional through-hole structure. Due to the excellent high-temperature strength, wear resistance, and thermal shock resistance of SiC filter membranes, this unique structural design exhibits irreplaceable comprehensive performance in extreme environments.
